RCCN SB Snap Bushing

 RCCN SB Snap Bushing

RCCN SB Snap Bushing

RCCN SB Snap Bushing



RCCN SB Snap Bushing RCCN SB Snap Bushing RCCN SB Snap Bushing

Material：UL approved NYLON 66(black)，
fireproof 94V-2,oil and rot resistant
Page number:B66

Item No.

Mounting
HoleA
(mm)
Max. cable
range B
Covering
C
Height
L

Packing

Black
 		 White
SB-8 SB-8W 7.8 5.8 10.5 8.0
100pcs

SB-10 SB-10W 9.5 6.4 12.0 10.3
SB-13 SB-13W 12.7 8.0 15.0 10.3
SB-16 SB-16W 15.9 12.7 18.6 10.3
SB-19 SB-19W 19.0 14.3 21.7 10.3
SB-22 SB-22W 22.2 17.5 24.2 11.5
SB-26 SB-26W 25.5 19.1 28.5 11.5
SB-28 SB-28W 28.0 23.0 30.7 11.5
SB-30 SB-30W 30.0 24.1 33.3 11.5
SB-35 SB-35W 34.2 29.3 37.5 11.3
SB-38 SB-38W 38.1 29 42.1 11.4
SB-45 SB-45W 44.5 35.4 47.8 11.6
SB-50 SB-50W 50.1 41.6 54.6 11.8
