Page 288 - 上海日成品牌 RCCN 线槽 电缆接头 尼龙扎带 尼龙软管 接线端子
P. 288
Wide slot/finger design provides
greater sidewall rigidity and can
be used with a wide range of wire
bundle sizesb
Certificates:UL:E306674
CE:EN50085 RoHS,REACHb
Made of rigid PVC
Work Temperature:-40°C to 65°C
UL94 Flammability Rating of V-0
Provided with mounting holes
Available color:gray.white.blue.black
and other special colors
Special design: with score line at the
base of trunking, it makes
the fingers easy to separate from the
trunking no need to us cutter.
VDR1525FZ VDR1525FZW VDR1525FZE VDR1525FZB 15×25 8 10 5~15pcs
VDR2025FZ VDR2025FZW VDR2025FZE VDR2025FZB 20×25 8 10 5~15pcs
VDR2525FZ VDR2525FZW VDR2525FZE VDR2525FZB 25×25 8 10 10~25pcs
VDR3025FZ VDR3025FZW VDR3025FZE VDR3025FZB 30×25 8 10 12~28pcs
VDR4025FZ VDR4025FZW VDR4025FZE VDR4025FZB 40×25 8 10 20~35pcs
VDR5025FZ VDR5025FZW VDR5025FZE VDR5025FZB 50×25 8 10 12~28pcs
VDR1530FZ VDR1530FZW VDR1530FZE VDR1530FZB 15×30 8 12 8~15pcs
VDR2030FZ VDR2030FZW VDR2030FZE VDR2030FZB 20×30 8 12 25~35pcs
VDR2530FZ VDR2530FZW VDR2530FZE VDR2530FZB 25×30 8 12 25~35pcs
VDR3030FZ VDR3030FZW VDR3030FZE VDR3030FZB 30×30 8 12 25~35pcs
VDR4030FZ VDR4030FZW VDR4030FZE VDR4030FZB 40×30 8 12 30~40pcs
VDR5030FZ VDR5030FZW VDR5030FZE VDR5030FZB 50×30 8 12 40~50pcs
Wide Slot Wiring Duct
VDR6030FZ VDR6030FZW VDR6030FZE VDR6030FZB 60×30 8 12 50~60pcs
VDR2233FZ VDR2233FZW VDR2233FZE VDR2233FZB 22×33 6 10.5 25~35pcs
VDR3333FZ VDR3333FZW VDR3333FZE VDR3333FZB 33×33 8 12 35~45pcs
VDR2035FZ VDR2035FZW VDR2035FZE VDR2035FZB 20×35 8 12 30~40pcs
VDR3535FZ VDR3535FZW VDR3535FZE VDR3535FZB 35×35 8 12 35~45pcs
VDR5035FZ VDR5035FZW VDR5035FZE VDR5035FZB 50×35 8 12 40~60pcs
VDR2040FZ VDR2040FZW VDR2040FZE VDR2040FZB 20×40 8 12 16~22pcs
VDR2540FZ VDR2540FZW VDR2540FZE VDR2540FZB 25×40 8 12 20~35pcs
VDR3540FZ VDR3540FZW VDR3540FZE VDR3540FZB 35×40 8 12 30~45pcs
VDR4040FZ VDR4040FZW VDR4040FZE VDR4040FZB 40×40 8 12 60~70pcs
VDR6040FZ VDR6040FZW VDR6040FZE VDR6040FZB 60×40 8 12 100~115pcs
VDR8040FZ VDR8040FZW VDR8040FZE VDR8040FZB 80×40 8 12 120~135pcs
VDR10040FZ VDR10040FZW VDR10040FZE VDR10040FZB 100×40 8 12 120~135pcs
VDR12040FZ VDR12040FZW VDR12040FZE VDR12040FZB 120×40 8 12 140~155pcs
greater sidewall rigidity and can
be used with a wide range of wire
bundle sizesb
Certificates:UL:E306674
CE:EN50085 RoHS,REACHb
Made of rigid PVC
Work Temperature:-40°C to 65°C
UL94 Flammability Rating of V-0
Provided with mounting holes
Available color:gray.white.blue.black
and other special colors
Special design: with score line at the
base of trunking, it makes
the fingers easy to separate from the
trunking no need to us cutter.
VDR1525FZ VDR1525FZW VDR1525FZE VDR1525FZB 15×25 8 10 5~15pcs
VDR2025FZ VDR2025FZW VDR2025FZE VDR2025FZB 20×25 8 10 5~15pcs
VDR2525FZ VDR2525FZW VDR2525FZE VDR2525FZB 25×25 8 10 10~25pcs
VDR3025FZ VDR3025FZW VDR3025FZE VDR3025FZB 30×25 8 10 12~28pcs
VDR4025FZ VDR4025FZW VDR4025FZE VDR4025FZB 40×25 8 10 20~35pcs
VDR5025FZ VDR5025FZW VDR5025FZE VDR5025FZB 50×25 8 10 12~28pcs
VDR1530FZ VDR1530FZW VDR1530FZE VDR1530FZB 15×30 8 12 8~15pcs
VDR2030FZ VDR2030FZW VDR2030FZE VDR2030FZB 20×30 8 12 25~35pcs
VDR2530FZ VDR2530FZW VDR2530FZE VDR2530FZB 25×30 8 12 25~35pcs
VDR3030FZ VDR3030FZW VDR3030FZE VDR3030FZB 30×30 8 12 25~35pcs
VDR4030FZ VDR4030FZW VDR4030FZE VDR4030FZB 40×30 8 12 30~40pcs
VDR5030FZ VDR5030FZW VDR5030FZE VDR5030FZB 50×30 8 12 40~50pcs
Wide Slot Wiring Duct
VDR6030FZ VDR6030FZW VDR6030FZE VDR6030FZB 60×30 8 12 50~60pcs
VDR2233FZ VDR2233FZW VDR2233FZE VDR2233FZB 22×33 6 10.5 25~35pcs
VDR3333FZ VDR3333FZW VDR3333FZE VDR3333FZB 33×33 8 12 35~45pcs
VDR2035FZ VDR2035FZW VDR2035FZE VDR2035FZB 20×35 8 12 30~40pcs
VDR3535FZ VDR3535FZW VDR3535FZE VDR3535FZB 35×35 8 12 35~45pcs
VDR5035FZ VDR5035FZW VDR5035FZE VDR5035FZB 50×35 8 12 40~60pcs
VDR2040FZ VDR2040FZW VDR2040FZE VDR2040FZB 20×40 8 12 16~22pcs
VDR2540FZ VDR2540FZW VDR2540FZE VDR2540FZB 25×40 8 12 20~35pcs
VDR3540FZ VDR3540FZW VDR3540FZE VDR3540FZB 35×40 8 12 30~45pcs
VDR4040FZ VDR4040FZW VDR4040FZE VDR4040FZB 40×40 8 12 60~70pcs
VDR6040FZ VDR6040FZW VDR6040FZE VDR6040FZB 60×40 8 12 100~115pcs
VDR8040FZ VDR8040FZW VDR8040FZE VDR8040FZB 80×40 8 12 120~135pcs
VDR10040FZ VDR10040FZW VDR10040FZE VDR10040FZB 100×40 8 12 120~135pcs
VDR12040FZ VDR12040FZW VDR12040FZE VDR12040FZB 120×40 8 12 140~155pcs
