INNER CONNECTOR FITTINGS-ICM
   |
Item No. |
Thread length L |
Height H |
W. across flats W |
Std.Pkg. pcs |
|
D1 |
D2 |
||||
|
ICM-M
|
|||||
| M12*1.5 | M12*1.5 | 6.0 | 15 | 15 | 10 |
| M16*1.5 | M16*1.5 | 6.5 | 16 | 18 | 10 |
| M20*1.5 | M20*1.5 | 7.5 | 17 | 24 | 10 |
| M25*1.5 | M25*1.5 | 8.0 | 19 | 29 | 10 |
| M32*1.5 | M32*1.5 | 9.0 | 21 | 36 | 5 |
| M40*1.5 | M40*1.5 | 10.0 | 24 | 44 | 5 |
| M50*1.5 | M50*1.5 | 10.0 | 24 | 54 | 5 |
|
ICM-P
|
|||||
| PG7 | PG7 | 6.0 | 15 | 15 | 10 |
| PG9 | PG9 | 6.5 | 15 | 18 | 10 |
| PG11 | PG11 | 6.5 | 16 | 21 | 10 |
| PG13.5 | PG13.5 | 6.5 | 17 | 24 | 10 |
| PG16 | PG16 | 7.5 | 19 | 25 | 10 |
| PG21 | PG21 | 8.0 | 19 | 31 | 5 |
| PG29 | PG29 | 9.0 | 21 | 40 | 5 |
| PG36 | PG36 | 10.0 | 24 | 51 | 5 |
| PG48 | PG48 | 10.0 | 24 | 64 | 5 |
|
ICM-N
|
|||||
| NPT3/8" | NPT3/8" | 6.5 | 9.0 | 24 | 10 |
| NPT1/2" | NPT1/2" | 7.5 | 10.0 | 30 | 10 |
| NTP3/4" | NTP3/4" | 8.0 | 11.5 | 39 | 10 |
| NPT 1" | NPT 1" | 9.0 | 12.5 | 50 | 10 |
