2
lmax=19A
Insulated squareğ 0.5j1.5mm (AWG22-16)Max. cunrrentğ
RF1.25-3N #4 3.2mm 5.5 18.5 5.0
RFS1.25-3.5N #6 3.7mm 5.5 18.5 5.0
RFM1.25-3.5N #6 3.7mm 6.6 20.4 6.3
RFL1.25-3.5N #6 3.7mm 8.0 21.8 7.0
RFS1.25-4N #8 4.3mm 6.6 20.4 6.3 10.0 4.0
RFL1.25-4N #8 4.3mm 8.0 21.8 7.0
RFS1.25-5N #10 5.3mm 8.0 21.8 7.0
RFL1.25-5N #10 11.6 5.3mm27.8 11.0
RFS1.25-6N 1/4 11.6 6.4mm27.8 11.0
RF1.25-6N 1/4 6.4mm 11.6 27.8 11.0
RF1.25-8N 5/16 8.4mm 11.6 27.8 11.0
RF1.25-10N 3/8 10.5mm 13.6 31.5 13.9
RF1.25-12N 1/2 13.0mm 19.6 36.4 16.0
2
lmax=27A
Insulated squareğ 1.5j2.5mm (AWG16-14)Max. cunrrentğ
RF2-3N #4 3.2mm 6.6 18.8 4.8
RFS2-3.5N #6 3.7mm 6.6 18.8 4.8
RFM2-3.5N #6 3.7mm 6.6 20.4 6.3
RFL2-3.5N #6 3.7mm 8.5 22.8 7.4
RFS2-4N #8 4.3mm 6.6 20.4 6.3
RFL2-4N #8 4.3mm 8.5 22.8 7.8 10.0 4.5
RFS2-5N #10 5.3mm 8.5 22.8 7.8
Futures:Halogen free,temperature upto 105 °Cđ RFL2-5N #10 5.3mm 9.5 22.8 7.3
with easy insert insulator,easy to process,hard
connecting inside and groove construction. RF2-6N 1/4 6.4mm 12.0 27.8 11.0
Advantage:high quality material insure reliable RF2-8N 5/16 8.4mm 12.0 27.8 11.0
in electric connecting,conduct under higher RF2-10N 3/8 10.5mm 13.6 31.5 13.9
temperature,without poison when fired, RF2-12N 1/2 13.0mm 19.2 36.4 16.0
with easy insert insulator,easy to process.
hard connecting inside and groove Insulated squareğ 2.5j4mm (AWG14-12)Max. cunrrentğ
2
lmax=37A
construction,with high te
RF3.5-4N #8 4.3mm 8.0 24.5 7.7
RFS3.5-5N #10 5.3mm 8.0 24.5 7.7
RFL3.5-5N #10 5.3mm 12.0 27.9 7.7 13.5 6.4
RF3.5-6N 1/4 6.5mm 12.0 27.9 7.7
RF3.5-8N 5/16 8.4mm 15.0 32.0 13.5
RF3.5-10N 3/8 10.5mm 15.0 32.0 13.5
2
lmax=48A
Insulated squareğ 4j6mm (AWG12-10)Max. cunrrentğ
RF5.5-3.5N #6 3.7mm 7.2 22.7 6.1
RFS5.5-4N #8 4.3mm 7.2 22.7 6.1
RFL5.5-4N #8 4.3mm 9.5 26.0 8.3
RF5.5-5N #10 5.3mm 9.5 26.0 8.3
RF5.5-6N 1/4 6.5mm 12.0 29.5 10.5 13.5 6.4
RF5.5-8N 5/16 8.4mm 15.0 3 .0 13.3
RF5.5-10N 3/8 10.5mm 15.0 34.0 13.3
RF5.5-12N 1/2 13.0mm 19.2 38.6 16.0
