Note:instal led by crimp tool YYT-1



Insulated square：0.5～1.5mm2(22～16) Max. cunrrent：lmax=10A

Item No.	Thickness of material	DIMENSION						Color
		bφ	F	Dφ	d	H	L
	mm	mm	mm	mm	mm	mm	mm
FB 1.25-156	0.4	4.0	11.0	3.5	1.7	10.0	21.0	Red

Insulated square：1.5～2.5mm2(16～14) Max. cunrrent：lmax=15A

Item No.	Thickness of material	DIMENSION						Color
		bφ	F	Dφ	d	H	L
	mm	mm	mm	mm	mm	mm	mm
FB 2-156	0.4	4.0	11.0	4.0	2.3	10.0	21.0	Blue
FB 2-195	0.4	5.0	11.0	4.0	2.3	10.0	21.0

Insulated square：4～6mm2(12～10) Max. cunrrent：lmax=24A

Item No.	Thickness of material	DIMENSION						Color
		bφ	F	Dφ	d	H	L
	mm	mm	mm	mm	mm	mm	mm
FB 5.5-195	0.4	4.0	11.0	5.0	3.4	14.0	25.0	Yellow







RCCN  FA Insulated Bullet Sockets Terminals







Note:installed by crimp tool YYT-1



 Insulated square：0.5～1.5mm2(22～16) Max. cunrrent：lmax=10A

Item No.	Thickness of material	DIMENSION						Color
		bφ	Bφ	Dφ	d	F	L
	mm	mm	mm	mm	mm	mm	mm
FA 1.25-156	0.4	4.0	6.3	2.7	1.7	13.0	24.5	Red

Insulated square：1.5～2.5mm2(16～14) Max. cunrrent：lmax=15A
