Cable size: 0.5～1.5mm2（A.W.G.22～16) max current:Imax=19A material:purple copper thickness:0.75mm
|
Item No
|
Dimension |
| Fφ |
L |
E |
Dφ |
dφ |
| mm |
mm |
mm |
mm |
mm |
| PIN 1.25-9 |
1.9 |
13.8 |
9 |
3.4 |
1.7 |
| PIN 1.25-10 |
1.9 |
14.8 |
10 |
| PIN 1.25-12 |
1.9 |
16.8 |
12 |
| PIN 1.25-13 |
1.9 |
17.8 |
13 |
| PIN 1.25-18 |
1.9 |
22.8 |
18 |
|
|
Cable size: 1.5～2.5mm2（A.W.G.16～14) max current:Imax=27A material:purple copper thickness:0.8mm
|
Item No
|
Dimension |
| Fφ |
L |
E |
Dφ |
Cφ |
| mm |
mm |
mm |
mm |
mm |
| PIN 2-9 |
1.9 |
13.8 |
9 |
4.1 |
2.3 |
| PIN 2-10 |
1.9 |
14.8 |
10 |
| PIN 2-12 |
1.9 |
16.8 |
12 |
| PIN 2-13 |
1.9 |
17.8 |
13 |
| PIN 2-18 |
1.9 |
22.8 |
18 |
Insulated square：2.5～4mm2(AWG14～12)Max. cunrrent：lmax＝37A
|
Item No
|
Dimension |
| Fφ |
L |
E |
Dφ |
Cφ |
| mm |
mm |
mm |
mm |
mm |
| PIN 3.5-10 |
2.8 |
14.8 |
10 |
5.0 |
3.0 |
| PIN 3.5-13 |
2.8 |
19.8 |
13 |
5.0 |
3.0 |
Cable size: 4～6mm2（A.W.G.12～10) max current:Imax=48A material:purple copper thickness:1.0mm
|
Item No
|
Dimension |
| Fφ |
L |
E |
Dφ |
Cφ |
| mm |
mm |
mm |
mm |
mm |
| PIN 5.5-13 |
2.8 |
19.8 |
13 |
5.6 |
3.4 |
