Note:installed by crimp tool YYT-1
|
Insulated square：1.5～2.5mm2(AWG16～14)Max. cunrrent：lmax＝27A
|
Item No.
|
DIMENSION |
Color
|
America
Bolt no. |
Dia. of bolt |
B |
L |
F |
H |
Dφ |
| d2φ |
mm |
mm |
mm |
mm |
mm |
| RF1.25-3 |
#4 |
3.2mm |
5.7
|
17.8
|
4.95
|
10.0 |
4.3 |
Red
|
| RFS1.25-3.5 |
#6 |
3.7mm |
5.7
|
17.8
|
4.95
|
| RFM1.25-3.5 |
#6 |
3.7mm |
6.6
|
20.1
|
6.3
|
| RFL1.25-3.5 |
#6 |
3.7mm |
8.0
|
21.5
|
7
|
| RFS1.25-4 |
#8 |
4.3mm |
6.6
|
20.1
|
6.3
|
| RFL1.25-4 |
#8 |
4.3mm |
8.0
|
21.5
|
7
|
| RF1.25-5 |
#10 |
5.3mm |
8.0
|
21.5
|
7
|
| RFL1.25-5 |
#10 |
5.3mm |
9.8
|
23.0
|
8.5
|
| RFS1.25-6 |
1/4 |
6.5mm |
9.8
|
23.0
|
8.5
|
| RF1.25-6 |
1/4 |
6.5mm |
11.6
|
27.5
|
11.1
|
| RF1.25-8 |
5/1 |
8.4mm |
11.6
|
27.5
|
11.1
|
| RF1.25-10 |
3/8 |
10.5mm |
13.6
|
31.6
|
13.9
|
| RF1.25-12 |
1/2 |
13.0mm |
19.2
|
36.0
|
16.5
|
|
|
|
Insulated square：0.5～1.5mm2(AWG22～16)Max. cunrrent：Imax＝19A
|
Item No.
|
DIMENSION |
Color
|
America
Bolt no. |
Dia. of bolt |
B |
L |
F |
H |
Dφ |
| d2φ |
mm |
mm |
mm |
mm |
mm |
| RF 2－3 |
#4 |
3.2mm |
6.6 |
17.8 |
4.3 |
10.0 |
4.9 |
Blue
|
| RFS 2－3.5 |
#6 |
3.7mm |
6.6 |
17.8 |
4.3 |
| RFM 2-3.5 |
#6 |
3.7mm |
6.6 |
21.0 |
7.0 |
| RFL 2-3.5 |
#6 |
3.7mm |
8.5 |
22.5 |
7.75 |
| RFS 2-4 |
#8 |
4.3mm |
6.6 |
21.0 |
7.0 |
| RFL 2-4 |
#8 |
4.3mm |
8.5 |
22.5 |
7.75 |
| RFS 2-5 |
#10 |
5.3mm |
8.5 |
22.5 |
7.75 |
| RFL 2-5 |
#10 |
5.3mm |
9.5 |
22.5 |
7.25 |
| RF 2-6 |
1/4 |
6.5mm |
12.0 |
27.6 |
11.0 |
| RF 2-8 |
5/16 |
8.4mm |
12.0 |
27.6 |
11.0 |
| RF 2-10 |
3/8 |
10.5mm |
13.6 |
30.2 |
13.9 |
| RF 2-12 |
1/2 |
13.0mm |
19.2 |
36.5 |
16.5 |
Insulated square：2.5～4mm2(AWG14～12)Max. cunrrent：lmax＝37A
|
Item No.
|
DIMENSION |
Color
|
America
Bolt no. |
Dia. of bolt |
B |
L |
F |
H |
Dφ |
| d2φ |
mm |
mm |
mm |
mm |
mm |
| RF 3.5-4 |
#8 |
4.3mm |
8.0 |
24.5 |
7.7 |
13.5 |
6.7 |
Black
|
| RFS 3.5-5 |
#10 |
5.3mm |
8.0 |
24.5 |
7.7 |
| RFL 3.5-5 |
#10 |
5.3mm |
12.0 |
27.9 |
7.7 |
| RF 3.5-6 |
1/4 |
6.5mm |
12.0 |
27.9 |
7.7 |
| RF 3.5-8 |
5/16 |
8.4mm |
15.0 |
32.0 |
13.5 |
| RF 3.5-10 |
3/8 |
10.5mm |
15.0 |
32.0 |
13.5 |
Insulated square：4～6mm2(AWG12～10)Max. cunrrent：lmax=48A
|
Item No.
|
DIMENSION |
Color
|
America
Bolt no. |
Dia. of bolt |
B |
L |
F |
H |
Dφ |
| dφ |
mm |
mm |
mm |
mm |
mm |
| RF 5.5-3.5 |
#6 |
3.7mm |
7.2 |
21.4 |
5.9 |
13.5 |
6.7 |
Yellow
|
| RFS 5.5-4 |
#8 |
4.3mm |
7.2 |
21.4 |
5.9 |
| RFL 5.5-4 |
#8 |
4.3mm |
9.5 |
25.5 |
8.3 |
| RF 5.5-5 |
#10 |
5.3mm |
9.5 |
25.5 |
8.3 |
| RF 5.5-6 |
1/4 |
6.5mm |
12.0 |
31.5 |
13.0 |
| RF 5.5-8 |
5/16 |
8.4mm |
15.0 |
33.7 |
13.7 |
| RF 5.5-10 |
3/8 |
10.5mm |
15.0 |
33.7 |
13.7 |
| RF 5.5-12 |
1/2 |
13.0mm |
19.2 |
38.1 |
16.0 |
