Note:installed by crimp tool YYT-1
|
Insulation square：0.5～1.5mm2(AWG22～16)Max current：Imax＝19A
|
Item No .
|
DIMENSION
|
color
|
|
America
bolt no.
|
Dia. of bolt |
B |
L |
F |
H |
DΦ |
| d2 |
mm |
mm |
mm |
mm |
mm |
| RF1.25-3N |
#4 |
3.2mm |
5.5 |
18.5 |
5.0 |
11.0 |
4.0 |
Red |
| RFS1.25-3.5N |
#6 |
3.7mm |
5.5 |
18.5 |
5.0 |
| RFM1.25-3.5N |
#6 |
3.7mm |
6.6 |
20.4 |
6.3 |
| RFL1.25-3.5N |
#6 |
3.7mm |
8.0 |
21.8 |
7.0 |
| RFS1.25-4N |
#8 |
4.3mm |
6.6 |
20.4 |
6.3 |
| RFL1.25-4N |
#8 |
4.3mm |
8.0 |
21.8 |
7.0 |
| RF1.25-5N |
#10 |
5.3mm |
8.0 |
21.8 |
7.0 |
| RFL1.25-5N |
#10 |
5.3mm |
11.6 |
27.8 |
11.0 |
| RFS1.25-6N |
1/4 |
6.5mm |
11.6 |
27.8 |
11.0 |
| RF1.25-6N |
1/4 |
6.5mm |
11.6 |
27.8 |
11.0 |
| RF1.25-8N |
5/16 |
8.4mm |
11.6 |
27.8 |
11.0 |
| RF1.25-10N |
3/8 |
10.5mm |
13.6 |
31.5 |
13.9 |
| RF1.25-12N |
1/2 |
13.0mm |
19.6 |
36.4 |
16.0 |
Insulation square：1.5～2.5mm2(AWG16～14)Max current：lmax＝27A
|
Item No .
|
DIMENSION
|
color
|
|
America
bolt no.
|
Dia. of bolt |
B |
L |
F |
H |
DΦ |
| d2 |
mm |
mm |
mm |
mm |
mm |
| RF2-3N |
#4 |
3.2mm |
6.6 |
18.8 |
4.8 |
11.0 |
4.5 |
Blue |
| RFS2-3.5N |
#6 |
3.7mm |
6.6 |
18.8 |
4.8 |
| RFM2-3.5N |
#6 |
3.7mm |
6.6 |
20.4 |
6.3 |
| RFL2-3.5N |
#6 |
3.7mm |
8.5 |
22.8 |
7.4 |
| RFS2-4N |
#8 |
4.3mm |
6.6 |
22.4 |
6.3 |
| RFL2-4N |
#8 |
4.3mm |
8.5 |
22.8 |
7.8 |
| RFS2-5N |
#10 |
5.3mm |
8.5 |
22.8 |
7.8 |
| RFL2-5N |
#10 |
5.3mm |
9.5 |
22.8 |
7.3 |
| RF2-6N |
1/4 |
6.5mm |
12.0 |
27.8 |
11.0 |
| RF2-8N |
5/16 |
8.4mm |
12.0 |
27.8 |
11.0 |
| RF2-10N |
3/8 |
10.5mm |
13.6 |
31.5 |
13.9 |
| RF2-12N |
1/2 |
13.0mm |
19.2 |
36.4 |
16.0 |
Insulated square：2.5～4mm2(AWG14-12)Max. cunrrent：lmax=37A
|
Item No .
|
DIMENSION
|
color
|
|
America
bolt no.
|
Dia. of bolt |
B |
L |
F |
H |
DΦ |
| d2 |
mm |
mm |
mm |
mm |
mm |
| RF3.5-4N |
#8 |
4.3mm |
8.0
|
24.5
|
7.7
|
13.5 |
6.4 |
Black |
| RFS3.5-5N |
#10 |
5.3mm |
8.0
|
24.5
|
7.7
|
| RFL3.5-5N |
#10 |
5.3mm |
12.0
|
27.9
|
7.7
|
| RF3.5-6N |
1/4 |
6.5mm |
12.0
|
|
7.7
|
| RF3.5-8N |
5/16 |
8.4mm |
15.0
|
32
|
13.5
|
| RF3.5-10N |
3/8 |
10.5mm |
15.0
|
32
|
13.5
|
Insulation square：4～6mm2(AWG12～10)Max current：lmax=48A
|
Item No .
|
DIMENSION
|
color
|
|
America
bolt no.
|
Dia. of bolt |
B |
L |
F |
H |
DΦ |
| d2 |
mm |
mm |
mm |
mm |
mm |
| RF5.5-3.5N |
#6 |
3.7mm |
7.2 |
22.7 |
6.1 |
13.5 |
6.4 |
Yellow |
| RFS5.5-4N |
#8 |
4.3mm |
7.2 |
22.7 |
6.1 |
| RFL5.5-4N |
#8 |
4.3mm |
9.5 |
26.0 |
8.3 |
| RF5.5-5N |
#10 |
5.3mm |
9.5 |
26.0 |
8.3 |
| RF5.5-6N |
1/4 |
6.5mm |
12.0 |
29.5 |
10.5 |
| RF5.5-8N |
5/16 |
8.4mm |
15.0 |
34.0 |
13.3 |
| RF5.5-10N |
3/8 |
10.5mm |
15.0 |
34.0 |
13.3 |
| RF5.5-12N |
1/2 |
13.0mm |
19.2 |
38.6 |
16.0 |
