RCCN A-M Brass Cable Gland


RCCN A-M Brass Cable Gland


RCCN A-M Brass Cable Gland


RCCN A-M Brass Cable Gland
Thread:Metric
Material:A.C.F are made of copper with nickel .D is made of PA,B.E are made of NBR
Certificates:CE,EX
Operate temperature:-50°C to 250°C
Protection:IP68。
Product characterstics:Special design of part D and E,used with part F, can save your time,
large spread of cable sealing,good re-tensile,waterproof,ashproof,re-salty,
withstand impregnant like acid,alkali,alcohol,oil,grease




Item No		 CableRange
Φ		 Thread
Length
 		 +Nut Max
platethick  		 Joint
Length
L2+L3		 Spanner
size
A&F		 Std.Pkg
Pcs

M
A-M8*1.25-4.5 2-4.5 6 ≤2.5 13 11/11 100PCS
A-M12*1.5-6.5 3-6.5 6 ≤2.5 19 14/14
A-M14*1.5-6.5 3-6.5 6 ≤2.5 19 18/14
A-M14*1.5-8 4-8 7 ≤3.5 19 18/18
A-M16*1.5-8 4-8 7 ≤3.5 20 18/18
A-M16*1.5-10 5-10 7 ≤3.5 22 20/20
A-M18*1.5-10 5-10 7 ≤3.5 22 20/20
A-M18*1.5-12 6-12 7 ≤3.5 23 22/22
A-M20*1.5-12 6-12 8 ≤4.5 23 22/22
A-M20*1.5*14 10-14 8 ≤4.5 23 24/24
A-M22*1.5-12 6-12 8 ≤4.5 23 24/22
A-M22*1.5-14 10-14 8 ≤4.5 23 24/24
A-M24*1.5-14 10-14 8 ≤4.5 23 28/24 50PCS
A-M25*1.5-14 10-14 9 ≤4.5 23 28/24
A-M25*1.5-17 11-17 9 ≤4.5 23 28/28
A-M25*1.5-18 13-18 9 ≤4.5 23 30/30
A-M27*1.5-17 11-17 9 ≤4.5 23 30/28
A-M27*2.0-17 11-17 9 ≤4.5 23 30/28
A-M27*1.5-18 13-18 9 ≤4.5 23 30/30
A-M27*2.0-18 13-18 9 ≤5.5 23 30/30
A-M30*2.0-18 13-18 11 ≤5.5 32 36/30
A-M30*2.0-21 15-21 11 ≤5.5 32 36/36
A-M30*2.0-25 18-25 11 ≤5.5 32 40/40
A-M32*1.5-18 13-18 11 ≤5.5 32 34/30
A-M32*1.5-21 15-21 11 ≤5.5 32 36/36
A-M32*1.5-25 18-25 11 ≤5.5 32 40/40
A-M33*2.0-18 13-18 11 ≤5.5 32 34/30
A-M33*2.0-21 18-25 11 ≤5.5 32 36/36
A-M33*2.0-25 15-21 11 ≤5.5 32 40/40
A-M36*2.0-25 18-21 11 ≤5.5 32 40/40 5PCS
A-M36*2.0-28 19-28 11 ≤5.5 32 44/44
A-M40*1.5-25 18-25 11 ≤5.5 32 44/40
A-M40*1.5-28 19-28 11 ≤5.5 32 44/44
A-M40*1.5-32 22-32 11 ≤5.5 32 50/50
A-M42*2.0-32 22-32 11 ≤5.5 32 50/50
A-M48*2.0-32 22-32 11 ≤5.5 32 50/50
A-M48*2.0-38 30-38 11 ≤5.5 38 58/58
A-M50*1.5-32 22-32 11 ≤5.5 38 54/50
A-M50*1.5-38 30-38 11 ≤5.5 38 58/58
A-M54*2.0-38 30-38 11 ≤5.5 38 58/58
A-M56*2.0-38 330-38 11 ≤5.5 38 58/58
A-M60*2.0-44 34-44 14 ≤8.5 38 64/64
A-M63*1.5-44 34-44 14 ≤8.5 38 68/64
A-M64*2.0-44 34-44 14 ≤8.5 45 68/64
A-M72*2.0-55 42-52 15 ≤9.5 45 81/81 1PCS
A-M75*1.5-55 42-52 15 ≤9.5 50 81/81
A-M80*2.0-60 50-60 20 ≤13.5 50 86/86
A-M88*2.0-70 60-70 20 ≤13.5 50 96/96
A-M100*2.0-80 70-80 20 ≤13.5 50 110
A-M110-2.0-90 80-90 20 ≤13.5 50 125
A-M125*2.0-100 90-100 20 ≤13.5 50 135
PG
A-PG7-6.5 3-6.5 6 ≤2.5 19 14/14 100PCS
A-PG9-8 4-8 7 ≤3.5 20 18/18
A-PG9-10 5-10 7 ≤3.5 22 20/20
A-PG11-10 5-10 7 ≤3.5 23 20/20
A-PG11-12 6-12 7 ≤3.5 23 22/22
A-PG13.5-12 6-12 8 ≤4.5 23 22/22
A-PG13.5-14 10-14 8 ≤4.5 23 24/24
A-PG16-14 10-14 9 ≤4.5 23 24/24
A-PG16-17 11-17 9 ≤4.5 23 28/28 50PCS
A-PG21-18 13-18 9 ≤5.5 23 30/30
A-PG21-21 15-21 11 ≤5.5 32 36/36
A-PG29-25 18-25 11 ≤5.5 32 40/40 5PCS
A-PG29-28 19-28 11 ≤5.5 32 44/44
A-PG36-32 22-32 11 ≤5.5 32 50/50
A-PG36-38 30-38 11 ≤5.5 32 58/58
A-PG42-38 30-38 11 ≤5.5 38 58/58
A-PG48-44 34-44 14 ≤8.5 38 64/64
NPT
A-NPT1/4-6.5 3-6.5 6 ≤2.5 19 14/14 100PCS
A-NPT3/8-8 4-8 7 ≤3.5 20 18/18
A-NPT3/8-10 5-10 7 ≤3.5 22 20/20
A-NPT1/2-12 6-12 8 ≤4.5 23 22/22
A-NPT1/2-14 10-14 8 ≤4.5 23 24/24
A-NPT3/4-14 10-14 9 ≤4.5 23 28/24 50PCS
A-NPT3/4-17 11-17 9 ≤4.5 23 30/28
A-NPT3/4-18 13-18 9 ≤4.5 23 30/30
A-NPT1-18 13-18 11 ≤5.5 32 36/30
A-NPT1-21 15-21 11 ≤5.5 32 36/36
A-NPT1-25 18-25 11 ≤5.5 32 40/40
A-NPT1-1/4-25 18-25 11 ≤5.5 32 44/40 5PCS
A-NPT1-1/4-28 19-28 11 ≤5.5 32 44/44
A-NPT1-1/4-32 22-32 11 ≤5.5 32 50/50
A-NPT1-1/2-32 22-32 11 ≤5.5 32 50/50
A-NPT1-1/2-38 30-38 11 ≤5.5 32 58/58
A-NPT2-44 34-44 14 ≤8.5 38 64/64
A-NPT2-1/2-55 42-52 15 ≤9.5 50 81/81 1PCS
A-NPT3-70 60-70 20 ≤13.5 50 96/96
A-NPT3-1/2-80 70-80 20 ≤13.5 50 110
G
A-G1/4-6.5 3-6.5 6 ≤2.5 19 14/14 100PCS
A-G3/8-8 4-8 7 ≤3.5 20 18/18
A-G3/8-10 5-10 7 ≤3.5 22 18/18
A-G1/2-12 6-12 8 ≤4.5 23 22/22
A-G1/2-14 10-14 8 ≤4.5 23 24/24
A-G3/4-14 10-14 9 ≤4.5 23 28/24 50PCS
A-G3/4-17 11-17 9 ≤4.5 23 30/28
A-G3/4-18 13-18 9 ≤4.5 23 30/30
A-G1-18 13-18 11 ≤5.5 32 36/30
A-G1-21 15-21 11 ≤5.5 32 36/36
A-G1-25 18-25 11 ≤5.5 32 40/40
A-G1-1/4-25 18-25 11 ≤5.5 32 44/40 5PCS
A-G1-1/4-28 19-28 11 ≤5.5 32 44/44
A-G1-1/4-32 22-32 11 ≤5.5 32 50/50
A-G1-1/2-32 22-32 11 ≤5.5 32 50/50
A-G1-1/2-38 30-38 11 ≤5.5 32 58/58
A-G2-44 34-44 14 ≤8.5 38 64/64
A-G2-1/2-55 42-52 15 ≤9.5 50 81/81 1PCS
A-G3-70 60-70 20 ≤13.5 50 96/96
A-G3-1/2-80 70-80 20 ≤13.5 50 110
