RCCN VDRCT Close Slot Wiring Duct

RCCN VDRCT Close Slot Wiring Duct





RCCN VDRCT Close Slot Wiring Duct

American standard Narrow slot/finger design provides more slots
to closer fit the spacing of high-density terminal blocks and other
hardware used countries such as USA,
Certificates:UL:E306674 CE:EN50085 RoHS,REACH。
Made of rigid PVC
UL Recognized continuous use temperature: 50°C (122°F)
UL94 Flammability Rating of V-0
Provided with mounting holes
Available color:gray.white.blue.black and other special colors
Work Temperature:-40°C to 65°C

MOQ is requested color：gray white
RCCN VDRCT Close Slot Wiring Duct

T:Two protruded line in the top of the lids all of our wiring duct can be made in gray white  color code 2：gray white.



Item No.

W*H

Slot
width

Q

Finger
width

P

Wire
capability
/2.0sp

Standard
 Length
Gray White Blue Black
VDR2540CT2 VDR2540CTW VDR2540CTE VDR2540CTB 25*40 8.5 11.5 20~25pcs 112M
VDR4040CT2 VDR4040CTW VDR4040CTE VDR4040CTB 40*40 8.5 11.5 60~70pcs 100M
VDR6040CT2 VDR6040CTW VDR6040CTE VDR6040CTB 60*40 8.5 11.5 100~115pcs 68M
VDR8040CT2 VDR8040CTW VDR8040CTE VDR8040CTB 80*40 8.5 11.5 120~135pcs 48M
VDR10040CT2 VDR10040CTW VDR10040CTE VDR10040CTB 100*40 8.5 11.5 120~135pcs 32M
VDR2560CT2 VDR2560CTW VDR2560CTE VDR2560CTB 25*60 8.5 11.5 40~50pcs 100M
VDR4060CT2 VDR4060CTW VDR4060CTE VDR4060CTB 40*60 8.5 11.5 100~115pcs 60M
VDR6060CT2 VDR6060CTW VDR6060CTE VDR6060CTB 60*60 8.5 11.5 120~135pcs 48M
VDR8060CT2 VDR8060CTW VDR8060CTE VDR8060CTB 80*60 8.5 11.5 180~210pcs 36M
VDR10060CT2 VDR10060CTW VDR10060CTE VDR10060CTB 100*60 8.5 11.5 240~290pcs 28M
VDR2580CT2 VDR2580CTW VDR2580CTE VDR2580CTB 25*80 10 10 100~120pcs 72M
VDR4080CT2 VDR4080CTW VDR4080CTE VDR4080CTB 40*80 10 10 140~160pcs 48M
VDR6080CT2 VDR6080CTW VDR6080CTE VDR6080CTB 60*80 10 10 180~210pcs 32M
VDR8080CT2 VDR8080CTW VDR8080CTE VDR8080CTB 80*80 10 10 240~290pcs 24M
VDR10080CT2 VDR10080CTW VDR10080CTE VDR10080CTB 100*80 10 10 260~350pcs 24M
VDR25100CT2 VDR25100CTW VDR25100CTE VDR25100CTB 25*100 10 10 110~160pcs 60M
VDR40100CT2 VDR40100CTW VDR40100CTE VDR40100CTB 40*100 10 10 130~175pcs 40M
VDR60100CT2 VDR60100CTW VDR60100CTE VDR60100CTB 60*100 10 10 240~290pcs 32M
VDR80100CT2 VDR80100CTW VDR80100CTE VDR80100CTB 80*100 10 10 260~350pcs 24M
VDR100100CT2 VDR100100CTW VDR100100CTE VDR100100CTB 100*100 10 10 300~400pcs 24M



RCCN VDRCT Close Slot Wiring Duct



RCCN VDRCT Close Slot Wiring Duct  RCCN VDRCT Close Slot Wiring Duct


RCCN  Din Rails



RCCN VDRCT Close Slot Wiring Duct        RCCN VDRCT Close Slot Wiring Duct


RCCN VDRCT Close Slot Wiring Duct

RCCN VDRCT Close Slot Wiring Duct



Material:high quality and strength cold rolled steel with electroplate
EN50022 Product standard: EN50022
Color: yellow plated nickle,silver plated zinc
Operated temperature:-40°C standing heat to 100°C
Use way: fixed on the panel then installed with electric parts
Features: perfect design,with huge pressure,exactly dia., rust resistant
Special length or special hole come with MOQ., Rohs approved products are available.
TS-35/7.5/1/1M/R Environment-friendly goods’ part no.:TS-35/7.5/1/1M/ROHS





Item No.
Outer width/Outer height/
Thickness/Length 		 Material Length
per pcs		 Packing/
carton
TS-35/7.5   Series
TS-35/7.5/1.0/1M Color zinc steel 1M 50M
TS-35/7.5/1.0/1M-ROHS ROHS silver zinc plated steel 1M 50M
TS-35/7.5/1.0/2M Color zinc steel 2M 100M
TS-35/7.5/1.0/2M-ROHS ROHS silver zinc plated steel 2M 100M
TS-35/15  Series
TS-35/15/1.5/1M Color zinc steel 1M 30M
TS-35/15/1.5/1M-ROHS ROHS silver zinc plated steel 1M 30M
TS-35/15/1.5/2M Color zinc steel 2M 60M
TS-35/15/1.5/2M-ROHS ROHS silver zinc plated steel 2M 60M
LSC-35/7.5/1.1  Series
LSC-35/7.5/1.1/1M ROHS Aluminum metal 1M 100M
LSC-35/7.5/1.1/2M ROHS Aluminum metal 2M 100M
LSC-35/7.5/1.1/1M-No bottom ROHS Aluminum metal 1M 100M
LSC-35/7.5/1.1/2M-No bottom ROHS Aluminum metal 2M 100M
LS-35/7.5/1.5 Series
LS-35/7.5/1.5/1M ROHS Aluminum metal 1M 100M
LS-35/7.5/1.5/2M ROHS Aluminum metal 2M 100M
LS-35/7.5/1.5/1M-No bottom ROHS Aluminum metal 1M 100M
LS-35/7.5/1.5/2M-No bottom ROHS Aluminum metal 2M 100M
