日成PAV0尼龙阻燃波纹管

材       质: 进口PA6 尼龙(Polyamide)
温       度:-40℃-125℃,短时达到150℃
防火等级:94-V0。
产品认证: 欧洲CE, 欧洲环保ROHS,REACH.
特       性:柔软有韧性，抗扭曲；机械强度好，可以承受重的负载；耐酸，耐切屑液，润滑油，冷却液等；表面有光泽，耐摩擦；黑色耐紫外线，机械强度高；
用       途:可保护电线电缆不受外力磨损及绝缘承载能力:可以承受脚踩和更高强度的重压，不变形，但可以迅速恢复并且本身无任何损伤.
应用场合:风电发电, 地铁轨道,电力机车的车厢内使用；机械制造,电气绝缘保护,公共交通设备;照明设备;汽车制造;航空设备；
使用方法:将电线电缆穿入管内，再配合日成系列软管接头使用即可
备       注:特殊包装长度有起订量要求。
目录页码:A52

型号 Item No.	规格 Sizes	内径 I.D. A	外径 O.D. B	静态弯曲半径	动态弯曲半径	包装 Packing M
黑色阻燃剖开Black Ral9005
BGR-07NBV0	1/4''	6.5	10.0	13	35	100M
BGR-10NBV0	5/16''	10.0	13.0	20	45	100M
BGR-12NBV0	-	12.0	15.8	35	55	100M
BGR-15NBV0	3/8''	14.3	18.5	40	65	100M
BGR-17NBV0	1/2''	17.0	21.2	45	75	100M
BGR-23NBV0	3/4''	23.0	28.5	55	100	50M
BGR-29NBV0	1''	29.0	34.5	65	120	50M
BGR-36NBV0	1 1/4''	36.0	42.5	90	150	50M
BGR-48NBV0	2''	48.0	54.5	100	190	25M
BGR-08NBV0	9/32''	8.0	11.5	13	25	100M
BGR-11NBV0	-	11.0	14.0	20	45	100M
BGR-16NBV0	-	14.5	20.0	45	75	100M
BGR-20NBV0	-	20.0	25.0	50	85	50M
BGR-25NBV0	-	25.0	31.5	50	110	50M
深灰阻燃剖开Gray Ral7037
BGR-07NGV0	1/4''	6.5	10.0	13	35	100M
BGR-10NGV0	5/16''	10.0	13.0	20	45	100M
BGR-12NGV0	-	12.0	15.8	35	55	100M
BGR-15NGV0	3/8''	14.3	18.5	40	65	100M
BGR-17NGV0	1/2''	17.0	21.2	45	75	100M
BGR-23NGV0	3/4''	23.0	28.5	55	100	50M
BGR-29NGV0	1''	29.0	34.5	65	120	50M
BGR-36NGV0	1 1/4''	36.0	42.5	90	150	50M
BGR-48NGV0	2''	48.0	54.5	100	190	25M
BGR-08NGV0	9/32''	8.0	11.5	13	25	100M
BGR-11NGV0	-	11.0	14.0	20	45	100M
BGR-16NGV0	-	14.5	20.0	45	75	100M
BGR-20NGV0	-	20.0	25.0	50	85	50M
BGR-25NGV0	-	25.0	31.5	50	110	50M
白色White Ral9012
BG-07NW	1/4''	6.5	10.0	13	35	100M
BG-10NW	5/16''	10.0	13.0	20	45	100M
BG-12NW	-	12.0	15.8	35	55	100M
BG-15NW	3/8''	14.3	18.5	40	65	100M
BG-17NW	1/2''	17.0	21.2	45	75	100M
BG-23NW	3/4''	23.0	28.5	55	100	50M
BG-29NW	1''	29.0	34.5	65	120	50M
BG-36NW	1 1/4''	36.0	42.5	90	150	50M
BG-48NW	2''	48.0	54.5	100	190	25M
BG-08NW	9/32''	8.0	11.5	13	25	100M
BG-11NW	-	11.0	14.0	20	45	100M
BG-16NW	-	14.5	20.0	45	75	100M
BG-20NW	-	20.0	25.0	50	85	50M
BG-25NW	-	25.0	31.5	50	110	50M
白色阻燃White Ral9012
BGR-07NW	1/4''	6.5	10.0	13	35	100M
BGR-10NW	5/16''	10.0	13.0	20	45	100M
BGR-12NW	-	12.0	15.8	35	55	100M
BGR-15NW	3/8''	14.3	18.5	40	65	100M
BGR-17NW	1/2''	17.0	21.2	45	75	100M
BGR-23NW	3/4''	23.0	28.5	55	100	50M
BGR-29NW	1''	29.0	34.5	65	120	50M
BGR-36NW	1 1/4''	36.0	42.5	90	150	50M
BGR-48NW	2''	48.0	54.5	100	190	25M
BGR-08NW	9/32''	8.0	11.5	13	25	100M
BGR-11NW	-	11.0	14.0	20	45	100M
BGR-16NW	-	14.5	20.0	45	75	100M
BGR-20NW	-	20.0	25.0	50	85	50M
BGR-25NW	-	25.0	31.5	50	110	50M
白色剖开White Ral9012
BGR-07NW	1/4''	6.5	10.0	13	35	100M
BGR-10NW	5/16''	10.0	13.0	20	45	100M
BGR-12NW	-	12.0	15.8	35	55	100M
BGR-15NW	3/8''	14.3	18.5	40	65	100M
BGR-17NW	1/2''	17.0	21.2	45	75	100M
BGR-23NW	3/4''	23.0	28.5	55	100	50M
BGR-29NW	1''	29.0	34.5	65	120	50M
BGR-36NW	1 1/4''	36.0	42.5	90	150	50M
BGR-48NW	2''	48.0	54.5	100	190	25M
BGR-08NW	9/32''	8.0	11.5	13	25	100M
BGR-11NW	-	11.0	14.0	20	45	100M
BGR-16NW	-	14.5	20.0	45	75	100M
BGR-20NW	-	20.0	25.0	50	85	50M
BGR-25NW	-	25.0	31.5	50	110	50M
桔红色Orange Ral2003
BG-07NO	1/4''	6.5	10.0	13	35	100M
BG-10NO	5/16''	10.0	13.0	20	45	100M
BG-12NO	-	12.0	15.8	35	55	100M
BG-15NO	3/8''	14.3	18.5	40	65	100M
BG-17NO	1/2''	17.0	21.2	45	75	100M
BG-23NO	3/4''	23.0	28.5	55	100	50M
BG-29NO	1''	29.0	34.5	65	120	50M
BG-36NO	1 1/4''	36.0	42.5	90	150	50M
BG-48NO	2''	48.0	54.5	100	190	25M
BG-08NO	9/32''	8.0	11.5	13	25	100M
BG-11NO	-	11.0	14.0	20	45	100M
BG-16NO	-	14.5	20.0	45	75	100M
BG-20NO	-	20.0	25.0	50	85	50M
BG-25NO	-	25.0	31.5	50	110	50M
桔红色剖开Orange Ral2003
BGR-07NO	1/4''	6.5	10.0	13	35	100M
BGR-10NO	5/16''	10.0	13.0	20	45	100M
BGR-12NO	-	12.0	15.8	35	55	100M
BGR-15NO	3/8''	14.3	18.5	40	65	100M
BGR-17NO	1/2''	17.0	21.2	45	75	100M
BGR-23NO	3/4''	23.0	28.5	55	100	50M
BGR-29NO	1''	29.0	34.5	65	120	50M
BGR-36NO	1 1/4''	36.0	42.5	90	150	50M
BGR-48NO	2''	48.0	54.5	100	190	25M
BGR-08NO	9/32''	8.0	11.5	13	25	100M
BGR-11NO	-	11.0	14.0	20	45	100M
BGR-16NO	-	14.5	20.0	45	75	100M
BGR-20NO	-	20.0	25.0	50	85	50M
BGR-25NO	-	25.0	31.5	50	110	50M

本品为定做产品，有起订量要求，本品NB1与NB弯曲性能一样，与NB型区别是产品圆圈的环刚性硬度降低表面柔软。
采用进口PA6软质料制成。

柔软型-型号 Item No .		规格 Sizes	内径 I.D. A	外径 O.D. B	包装 Packing M
黑色阻燃	灰色阻燃	规格 Sizes	内径 I.D. A	外径 O.D. B	包装 Packing M
BG-07NB1V0	BG-07NG1V0	1/4''	6.5	10.0	100M
BG-10NB1V0	BG-10NG1V0	5/16''	10.0	13.0	100M
BG-12NB1V0	BG-12NG1V0	-	12.0	15.8	100M
BG-15NB1V0	BG-15NG1V0	3/8''	14.3	18.5	100M
BG-17NB1V0	BG-17NG1V0	1/2''	17.0	21.2	100M
BG-23NB1V0	BG-23NG1V0	3/4''	23.0	28.5	50M
BG-29NB1V0	BG-29NG1V0	1''	29.0	34.5	50M
BG-36NB1V0	BG-36NG1V0	1 1/4''	36.0	42.5	50M
BG-48NB1V0	BG-48NG1V0	2''	48.0	54.5	25M
BG-11NB1V0	BG-11NG1V0	-	11.0	14.0	100M
BG-20NB1V0	BG-20NG1V0	-	20.0	25.0	50M
BG-25NB1V0	BG-25NG1V0	-	25.0	32.0	50M
